Beams And Columns Strengthening
| Property | Description |
|---|---|
| Strengthening Method | FRP Wrapping / Steel Jacketing / RCC Jacketing / Epoxy Injection |
| Base Material | Carbon fiber, glass fiber, epoxy resin, micro-concrete, or steel plates |
| Application Method | Surface preparation, bonding, wrapping, and curing as per design |
| Recommended Areas | Columns, beams, slabs, bridges, and load-bearing structures |
| Surface Preparation | Removal of loose concrete, cleaning, and application of bonding agent |
| Compressive Strength (Micro-concrete) | ≥ 40 MPa after 28 days |
| Tensile Strength (FRP System) | Up to 3500 MPa |
| Bond Strength | ≥ 1.5 MPa (Concrete to FRP / Steel) |
| Temperature Resistance | -10°C to +80°C (depends on system type) |
| Corrosion Resistance | Excellent, prevents steel reinforcement deterioration |
| Durability | High – suitable for seismic and heavy-load applications |
| Compatibility | Compatible with concrete and steel substrates |
| Curing Time | 24–48 hours depending on material and ambient temperature |
Beams and Columns Strengthening is a structural rehabilitation technique aimed at enhancing the load-bearing capacity, stiffness, and durability of existing reinforced concrete members. This process involves the use of high-performance materials such as fiber-reinforced polymers (FRP), micro-concrete jacketing, or steel plate bonding to restore structural integrity and extend service life. It is ideal for structures showing cracks, deformation, corrosion damage, or requiring higher load performance due to design modifications, ensuring improved strength, safety, and stability.
